FeeTech FT90M 2.3kg digital servo 280°
FeeTech FT90M 2.3kg digital servo 280°
Regular price
$12.00 USD
Regular price
Sale price
$12.00 USD
Unit price
per
Couldn't load pickup availability
The perfect servo for your pan cam. Offering 280° of rotation out of the box and combined with the field of view of current cameras you can easy achieve a entire look around yourself.
The FT90M is a digital micro servo motor with an operating voltage between 3V to 8.4V. The servo features metal gears providing a long lifespan and high torque, suitable for robotic and general purpose applications.
- Type: digital
- Speed: 0.12(4.8V), 0.1(6V) sec/60°
- Torque: 1.9(4.8V), 2.3(6V) kg/cm
- Rotation: 280°
- Operating voltage: 3-8.4V
- Gears: metal
- Cable length: 250mm
- Weight: 13.5g
- Dimensions: 23.3 x 12.1 x 25.5mm (LxWxH)
detailed specs:
| No Load Speed | 0.125sec/60degree at 4.8V |
| Weight | 13.5g |
| Gear Type | Metal |
| Operating Temperature | -20°C to +60°C |
| Total Rotation | 280° |
| Running Current | 120mA at 4.8V |
| Input Voltage | 3-8.4V |
| height | 25.25mm |
| Width | 12.1mm |
| Manufacturer | Feetech |
| Type | Digital |
| Gear Spline | 20T |
| Length | 23.2mm |
| Input Voltage | 3-8.4V |
| Cable Length | 250mm |
| Peak Stall Torque | 1.89kg.cm at 4.8V |
| Idle Current | 5mA at 4.8V |
| Stall Current | 800mA at 4.8V |
| MPN | FT90M |
| Country of Manufacture | China |
